No. 13S054-10
STC-HD203DV / STC-HD203DV-CS / STC-HD203SDI / STC-HD203SDI-CS
Product Specifications and Users Guide
40/78
Address
7
6
5
4
3
2
1
0
Descriptions Default
02C -
038
X
X
X
X
X
X
X
X
Reserved -
039 X
X
X
X
X
X
X
X
Default function of primary switch WB: single push
* As for the detail of selectable function, please refer to Push
button function list
2
03A X
X
X
X
X
X
X
X
Default function of external switch A: single push
* As for the detail of selectable function, please refer to Push
button function list
1
03B X
X
X
X
X
X
X
X
Default function of external switch B: single push
* As for the detail of selectable function, please refer to Push
button function list
0
03C X
X
X
X
X
X
X
X
Default function of external switch C: single push
* As for the detail of selectable function, please refer to Push
button function list
0
03D X
X
X
X
X
X
X
X
Default function of external switch D: single push
* As for the detail of selectable function, please refer to Push
button function list
0
03E X
X
X
X
X
X
X
X
Default function of external switch E: single push
* As for the detail of selectable function, please refer to Push
button function list
0
03F X
X
X
X
X
X
X
X
Default function of external switch F: single push
* As for the detail of selectable function, please refer to Push
button function list
0
040 -
048
X
X
X
X
X
X
X
X
Reserved -
049 X
X
X
X
X
X
X
X
Default function of primary switch WB: hold
* As for the detail of selectable function, please refer to Push
button function list
3
04A X
X
X
X
X
X
X
X
Default function of external switch A: hold
* As for the detail of selectable function, please refer to Push
button function list
0
04B X
X
X
X
X
X
X
X
Default function of external switch B: hold
* As for the detail of selectable function, please refer to Push
button function list
0
04C X
X
X
X
X
X
X
X
Default function of external switch C: hold
* As for the detail of selectable function, please refer to Push
button function list
0
04D X
X
X
X
X
X
X
X
Default function of external switch D: hold
* As for the detail of selectable function, please refer to Push
button function list
0
04E X
X
X
X
X
X
X
X
Default function of external switch E: hold
* As for the detail of selectable function, please refer to Push
button function list
0
04F X
X
X
X
X
X
X
X
Default function of external switch F: hold
* As for the detail of selectable function, please refer to Push
button function list
0
To Next Page
