No. 13S054-10
STC-HD203DV / STC-HD203DV-CS / STC-HD203SDI / STC-HD203SDI-CS
Product Specifications and Users Guide
41/78
Address
7
6
5
4
3
2
1
0
Descriptions Default
050 X
X
X
OSD menu color
0: Black 1: Blue
2: Green 3: Cyan
4: Red 5: Magenta
6: Yellow 7: White
7
X
OSD character size
0: Large 1: Small
0
X
X
X
X
Reserved -
051 X
X
X
X
X
X
X
X
OSD horizontal display position
0: Left to 256: Right
0
052 X
X
X
X
X
X
X
X
OSD vertical display position
0: Top to 256: Bottom
0
053 -
054
X
X
X
X
X
X
X
X
Reserved -
055 X
Still Image
0: Off (Movie) 1: On (Still image)
0
X
X
Test Pattern selection
0: Off (Camera image) 1: Gray Scale
2: Color Bar
3: Color Bar + Gray Scale
0
X
X
X
X
X
Reserved -
056 X
X
X
X
X
X
X
Digital Zoom
M = 128 / (128 - x)
M: Magnification, x: Setting Parameter
0
X
Reserved -
057 X
X
X
X
X
X
X
X
Reserved -
058 X
X
X
X
X
X
X
X
Digital zoom pan (Horizontal Offset) [little-endian]
Two's complement
0
059 X
X
X
X
X
X
X
X
X
Reserved -
05A X
X
X
X
X
X
X
X
Digital zoom tilt(Vertical Offset) [little-endian]
Two's complement
0
05B X
X
X
X
X
X
X
X
X
Reserved -
05C X
X
X
X
X
X
X
X
Horizontal line min position [little-endian] (to Push Button) 0
05D 0
0
0
0
0
X
X
X
05E X
X
X
X
X
X
X
X
Horizontal line max position [little-endian] (to Push Button) 1,920
05F 0
0
0
0
0
X
X
X
060 X
X
X
X
X
X
X
X
Horizontal line max thickness [little-endian] (to Push Button) 1,920
061 0
0
0
0
0
X
X
X
062 X
X
X
X
X
X
X
X
Vertical line min position [little-endian] (to Push Button) 0
063 0
0
0
0
0
X
X
X
064 X
X
X
X
X
X
X
X
Vertical line max position [little-endian] (to Push Button) 1,080
065 0
0
0
0
0
X
X
X
066 X
X
X
X
X
X
X
X
Vertical line max thickness [little-endian] (to Push Button) 1,080
067 0
0
0
0
0
X
X
X
