No. 13S054-10
STC-HD203DV / STC-HD203DV-CS / STC-HD203SDI / STC-HD203SDI-CS
Product Specifications and Users Guide
50/78
Address
7
6
5
4
3
2
1
0
Descriptions Default
030 X
X
White Balance Mode
0: Auto 1: Full Open
2: AWB Hold 3: USER Mode
0
X
X
X
X
X
Reserved -
X
Push Lock (After the Push Lock, White Balance mode turn to the
AWB mode automatically)
0:OFF 1:ON (Automatically turn 0, after convergence)
0
031 X
X
X
X
X
X
X
X
AWB Pull-in Delay Unit: Frame number
When a status outside the dead band has been detected in the
ATW mode,
pull-in is started after achieving consistency in the number of
frames specified by the this parameter.
8
032 X
X
X
X
X
X
X
X
AWB Pull-in Speed Unit: Frame number
Pull-in speed of ATW mode is set in the number of frames
specified by this parameter.
This register is available in Auto, or Full Open on White Balance
Mode
1
033 X
X
X
X
X
X
X
X
Convergence Step inside target area
The ATW pull-in steps inside target area can be indicated.
When set step shortly, the convergence speed of white balance is
faster.
12
034 X
X
X
X
X
X
X
X
Convergence Step outside target area
The ATW pull-in steps outside target area can be indicated.
When set step shortly, the convergence speed of white balance is
faster.
12
035 X
X
X
X
X
X
X
X
Pull-in Step for Full Open
When set the number of steps for full open mode pull-in,
the convergence speed is faster.
2
036 X
X
X
X
X
X
X
X
User Mode fixed coordinate R/G
This register is available on USER mode
2,453
037 X
X
X
X
X
X
X
X
038 X
X
X
X
X
X
X
X
User Mode fixed coordinate B/G
This register is available on USER mode
7,295
039 X
X
X
X
X
X
X
X
03A -
03F
X
X
X
X
X
X
X
X
Reserved -
040 0
0
0
0
X
X
X
X
Resolution/FrameRate
0: 1080P 60 fps 1: 1080P 30 fps
2: 1080P 50 fps 3: 1080P 25 fps
6: 720P 60 fps 7: 720P 50 fps
10: 1080P 59.94 fps 11: 1080P 29.97 fps
13: 720P 59.94 fps
Please do not select other value.
0
041 X
X
Image Output Inversion
0: Standard 1: H Inversion
2: V Inversion 3: HV Inversion
0
X
X
X
X
X
X
Reserved -
042 X
X
X
X
X
X
X
X
Reserved -
To Next Page
