3-4SectionIR and DM Areas
47
For normal mode, set the operation mode switch on the rear panel of the Unit as
shown in the following diagram.
The allocation of IR words and bits is shown in the following table.
I/O Word
Bits
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Output
o
CPU)
16
1
16
0
8 7 6 5 4 3 2 1
Note For the IR word addresses, n = 100 + 10 x unit number.
For Units #A to #F (10 to 15), n = 400 + 10 x (unit number – 10).
Set Values and Stored Values
Item Contents
Conversion enable 0: Stop conversion output
1: Begin conversion output
Set value 16-bit binary data
Output setting error 0: No error
1: Output setting error
Error code Two digits, hexadecimal (00 for no error)
Allocation for Normal
Mode
