Omron SYSMAC C20P Installation Guide

36
The inputs can use the Unit’s 24-VDC power supply output. If the maximum
output current of 0.3 A is not sufficient, however, a separate DC power supply
must be used.
Relay contact outputs
Transistor outputs
Triac outputs
Power
supply
(100 to
240
VAC)
Ground
Upper terminal block
Lower terminal block
Inputs (24 VDC)
24-VDC
output
(0.3 A
max.)
M3.5 screws
7.5 max.
7.5 max.
Load
power
supply
Load
power
supply
Load
power
supply
Load
power
supply
Load power
supply
100 240VAC
CH(00 15) CH(00 15)
CH(00 15)
CH(00 11)
INPUT
COM
NC NC
NC
I/O Unit C60P (EDj-A)
I/O Wiring Section 2-6
