42
I/O Link Unit 3G2C7-LK011(-P)E
RUN output
M4 screws
Repeater output (Used only when connected to Link Adapter.)
Link Adapter
M4 screws
Optical fiber connector
Power supply
(100 to 240 VAC)
8.6 max.
8.6 max.
I/O Wiring Section 2-6
