Omron SYSMAC C28K Installation Guide

24
Inputs 0000 and 0001 can use the Unit’s 24–VDC power supply output. If the
maximum output current of 0.2 A is not sufficient a separate DC power sup-
ply must be used. Inputs 0002 to 0107 take a 100–VAC power supply.
0000, 0001
24–VDC inputs
0002 to 0101
100–VAC inputs
Relay contact outputs
Triac outputs
Power
supply
(100 to
240 VAC)
NC
NC
Ground
Not in C20K Not in C20K or C28K
Not in C20K
Not in C20K or C28K
High–
speed
counter
input
24 VDC
output
(0.2 A max.)
100 to 120 VAC
M3.5 screws
7.5 max.
7.5 max.
Load
power
supply
Load
power
supply
Load
power
supply
Load
power
supply
Load
power
supply
Load
power
supply
Load
power
supply
Hardware
reset input
CPU C20K, C28K, C40K
(CA_–A)
I/O Wiring Section 2–6
