Omron SYSMAC C40P User Manual

37
I/O Unit C60P (EAj-A)
Relay contact outputs
Triac outputs
Power
supply
(100 to
240
VAC)
Ground
Upper terminal block
Lower terminal block
Inputs (100 VAC)
24-VDC
output
(0.3 A
max.)
M3.5 screws
7.5 max.
7.5 max.
Load
power
supply
Load
power
supply
Load
power
supply
Load
power
supply
Load power
supply
100 240VAC
CH(00 15) CH(00 15)
CH(00 15)
CH(00 11)
INPUT
COM
NC NC
NC
I/O Unit C60P (EDj-D) A separate power supply must be used for the DC inputs.
Relay contact outputs
Transistor outputs
Power
supply
(24
VDC)
Ground
Upper terminal block
Lower terminal block
Inputs (24 VDC)
M3.5 screws
7.5 max.
7.5 max.
Load
power
supply
Load
power
supply
Load
power
supply
Load
power
supply
Load power
supply
Load power
supply
100 240VAC
CH(00 15) CH(00 15)
CH(00 15)
CH(00 11)
INPUT
NC NC
NC
NC
NC
I/O Wiring Section 2-6

Omron SYSMAC C40P Specifications

General

Model	C40P
Type	Programmable Logic Controller (PLC)
Manufacturer	Omron
Series	SYSMAC
Number of Inputs	24
Number of Outputs	16
Operating Temperature	0 to 55 °C
Humidity	10 to 90% RH (non-condensing)
Input Voltage	100-240V AC
Communication Ports	RS-232C
Programming Language	Ladder Diagram
Instruction Set	Basic and advanced instructions
Timer/Counter	Yes
Storage Temperature	-20 to 70 °C
I/O Capacity	40 points (24 inputs, 16 outputs)
