67
Appendix B
Specifications
General Ratings
General Ratings
Supply voltage
Operating voltage range
Power consumption
24-VDC output*
Insulation resistance
Dielectric strength
Noise immunity
Vibration
Shock
Ambient temperature
Humidity
Grounding
Structure
Weight CPUs
Expan. I/O Units
Dimensions (CPUs and
Expan. I/O Units)
-A suffix: 100 to 240 VAC 50/60 Hz
-D suffix: 24 VDC
-A suffix: 85 to 264 VAC
-D suffix: 20.4 to 26.4 VDC
-A suffix: 60 VA max.
-D suffix: 40 W max.
0.3 A 24 VDC +10% (Use as DC power supply)
10 MW min. (at 500 VDC) between AC terminals and housing**
2,000 VAC 50/60 Hz for 1 min (between AC terminals and housing), Leakage current: 10 mA max.
500 VAC 50/60 Hz for 1 minute (between DC terminals and housing), Leakage current: 1 mA max.
1,000 V p–p, pulse width: 100 ns to 1 ms, rise time 1 ns
10 to 35 Hz, 2 mm double amplitude, in X, Y, and Z directions; 2 hours each. (When mounted on a
DIN rail: 16.7 Hz, 1 mm double amplitude, in X, Y, and Z directions, 1 hour each.)
10 G in X, Y, and Z directions, 3 times each
Operating: 0% to 55%C
Storage: –20% to 65%C
35% to 85% (without compensation)
Less than 100 W
IEC IP-30 (mounted in a panel)
C20K, C28K: 1.9 kg max; C40K: 2.2 kg max.; C60K: 2.6 kg max.
C20P, C28P: 1.7 kg max.; C40P: 2.0 kg max.; C60P: 2.4 kg max.
C20K, C28K: 250 (W) x 110 (H) x 100 (D); C40K: 300 (W) x 110 (H) x 100 (D);
C60K: 350 (W) x 140 (H) x 100 (D)
*This output is not provided on models with the suffix -D in the model number (models accepting a DC supply voltage).
*Disconnect the LR terminal from the GR terminal when testing the insulation resistance. Failure to do so will destroy internal circuits.
