Omron SYSMAC C60K

28
CPU C60K (CD_–D) A separate power supply must be used for the DC inputs.
Relay contact outputs
Transistor outputs
Power
supply
(24
VDC)
Ground
Load power
supply
Load
power
supply
Load
power
supply
Load
power
supply
Load
power
supply
Upper terminal
block
Lower terminal
block
Inputs (24 VDC)
High–
speed
counter
input
Hardware reset input
M3.5 screws
7.5 max.
7.5 max.
I/O Wiring Section 2–6
