Unit Versions of CS/CJ-series Serial Communications Boards/Units 7
• Serial Communications Units
2. Confirming Unit Versions with Support Software
CX-Programmer version 5.0 can be used to confirm the unit version in the
Unit Manufacturing Information.
■Boards
In the I/O Table Window, right-click on the CPU Unit, and then select Unit
Manufacturing Information – Inner Board
■Units
1. In the I/O Table Window, right-click on the Serial Communications Unit,
and then select Unit Manufacturing Information.
2. The following Unit Manufacturing Information Dialog Box will be displayed.
CS1W-SCB21-V1
SERIAL COMMUNICATION BOARD
Lot No. 051020 Ver.1.3
MADE IN JAPAN
OMRON Corporation
Example: CS1W-SCB21-V1 CS-series
Serial Communications Board
Nameplate
Unit version 1.3
:
CS1W-SCU21-V1
SERIAL COMMUNICATION UNIT
Lot No. 051020 0000 Ver.1.3
OMRON Corporation
MADE IN JAPAN
Example: CS1W-SCU21-V1 CS-series
Serial Communications Unit
Nameplate
Unit version 1.3
To Next Page
