CompoWay/F Master Protocol Appendix B
Send Data Word Allocation (3rd Operand of PMCR(260))
Set the number of send bytes to twice the number of bytes in memory. This is necessary because the data is
converted to ASCII data before being sent. The frames are created and sent in order from the leftmost word to
rightmost word of the I/O memory address.
Receive Data Word Allocation (4th Operand of PMCR(260))
The received frames are stored in order from the leftmost word to rightmost word of the I/O memory address.
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0005 to 00FA hex (5 to 250 decimal)
+1 (Undefined) Node No.
(2 digits BCD)
00 to 99
+2 MRC (2 digits hex) SRC (2 digits hex) Set the command code for the required ser-
vice
+3 Number of send bytes (4 digits hex) Number of data bytes from the next byte
after the command code (MRC, SRC) until
the byte just before the ETX.
0000 to 03D8 hex (0 to 984 decimal)
Note: The data is converted to ASCII in the
communications line, so the number of data
bytes is doubled from S+4 and onwards.
+4
on
Send data (4 digits hex) The data specified in hexadecimal here will
be converted to ASCII and the number of
bytes specified in S+3 will be sent in word
order from the leftmost to the rightmost
word.
Send data
First word of
send data
Number of send data words
+0
+1
+2
+3
+4
(Undefined)
Number of send bytes
MRC
SRC
Node No.
1 2 3 4
5 6 7 8
Send data words Send frame
"56" "78" "12" "34"
Offset Contents (data format) Data
+0 Number of receive data words
(4 digits hex)
0003 to 00FA Hex (3 to 250 decimal)
+1 Response code (4 digits hex) The CompoWay/F command response code
will be stored in hexadecimal code
+2
on
Receive data (4 digits hex) The data from just after the response code
until just before the ETX is converted from
ASCII to hexadecimal and stored in order
from the leftmost word to the rightmost
word.
Receive data
storage words
+0
+1
+2
Number of receive data words
Response code
Receive data
1 2 3 4
5 6 7 8
Receive data words
Receive frame
"12" "34" "56" "78"
Rightmost word
Leftmost word
