CompoWay/F Master Protocol Appendix B
Variable Area Fill
(Sequence No. 613 (Hex 0265))
This sequence writes the same data from the address of the specified variable type to the specified node num-
ber.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
Variable Area Broadcast Send
(Sequence No. 614 (Hex 0266))
This sequence writes the same data from the address of the specified variable using a broadcast address.
Send Data Word Allocation (3rd Operand of PMCR(260))
Offset Contents (data format) Data
+0 Number of send data words Always 0006 hex (6 decimal)
+1 (Undefined) Node No.
(2 digits BCD)
00 to 99
+2 Variable type
(2 digits hex)
Set the area type (2 digits) and the first read
word (6 digits). The leftmost byte of the first write
address specifies the address and the rightmost
byte specifies the bit location. Set the rightmost
byte to 00 when bit access is not required.
+3 First write address (6 digits BCD)
+4 Number of elements
(4 digits BCD)
Set the number of elements to write.
+5 Number of bytes to write
(4 digits hex)
Set the write data.
Number of bytes to write
First word of
send data
Number of send data words
+0
+1
+2
+3
(Undefined)
First write address
Variable type
Node No.
+4
Number of elements
+5
Offset Contents (data format) Data
+0 Number of receive data words Always 0002 hex (2 decimal)
+1 Response code (4 digits hex) The CompoWay/F command response code
is stored in hexadecimal code.
Receive data
storage words
+0
+1
Number of receive data words
Response code
Write data
First word of
send data
(Undefined)
+1
+2
+3
First write address
Variable type
+4
Number of elements
+5
Number of send data words
+0
