463
Mitsubishi Computer Link Master (A-compatible 1C Frame, Model 1) Appendix E
Device Memory Fill as Bit Data (T/C Device Type)
(Sequence No. 817 (Hex 0331)) (Command Code: JW)
This sequence writes the bit (PV) data starting from the specified word + 7 in the CS/CJ-series CPU Unit to the
number of device points starting from the specified device address for the specified device type (T, C) in the
Mitsubishi Computer Link Module with the specified station number (and the PLC number that follows).
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260)
Offset Contents (data format) Data
+0
Number of send data words
(4 digits hex)
0008 to 00FA hex (8 to 250 decimal)
+1
Station No.
(2 digits hex)
PLC No.
(2 digits hex)
Station No.: 00 to FF hex
PLC No.: 00 to FF hex
+2
Device type (4 digits hex) Set the device type (2 characters) in
ASCII.
+3
Device No. (5 digits hex) Set the first write address of the write
data.
+4
(Undefined)
+5
(Undefined) Device words/
bits
(2 digits hex)
Set the number of device words/bits to
write.
+6
Number of send data bytes
(4 digits hex)
Specify the number of text data bytes
for the communications line (i.e., twice
the number of text bytes in S+6
onwards)
+7
Write data (4 digits hex) Set the write data.
+0
+1
+5
+2
+3
+4
+6
+7
Number of send data words
PLC No.Station No.
Number of send data bytes
Device type
Device No.
Write data
First word of
send data
(Undefined)
(Undefined)
Number of device
words/bits
Offset Contents (data format) Data
+0
Number of receive data words 0002 hex or 0003 hex (2 or 3 decimal)
+1
Station No.
(2 digits hex)
PLC No.
(2 digits hex)
Station No.: 00 to FF hex
PLC No.: 00 to FF hex
+2
Error code
(2 digits hex)
(Undefined) Stores the error code converted to
hexadecimal. No error code is stored
for normal completion.
Receive data
storage words
Number of receive data words
+0
+1
PLC No.
+2
Station No.
Error code
(Undefined)
