E5 @ K Digital Controller Write Protocol Appendix G
Write Level 1 Parameter 2 (Sequence No. 067 (Hex 0043))
Writes parameters in level 1 (cooling coefficient, dead band, manual reset value, hysteresis (heating), hystere-
sis (cooling), control period (heating), and control period (cooling)) to multiple units.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
Number of units × 8 + 2
+1 Number of units (4 digits Hex) 0001 to 0008
+2 1st unit
Unit No. (2 digits BCD)
00 to 31
+3 1st unit
Cooling coefficient (4 digits BCD)
0001 to 9999
+4 1st unit
Dead band (4 digits BCD)
0000 to 9999
+5 1st unit
Manual reset value (4 digits BCD)
0000 to 1000
+6 1st unit
Hysteresis (heating)
(4 digits BCD)
0001 to 9999
+7 1st unit
Hysteresis (cooling)
(4 digits BCD)
0001 to 9999
+8 1st unit
Control period (heating)
(4 digits BCD)
0001 to 0099
+9 1st unit
Control period (cooling)
(4 digits BCD)
0001 to 0099
•
•
•
+65
(max.)
8th unit
Control period (cooling)
(4 digits BCD)
0001 to 0099
First word of
send data
+0
+1
+2
+3
+4
+5
+6
+7
+8
+9
+58
+59
+60
+61
+62
+63
+64
+65
Cooling coefficient
Dead band
Manual reset value
~ ~
Cooling coefficient
Dead band
Manual reset value
Hysteresis (heating)
1st unit
8th unit (max.)
Hysteresis (heating)
Hysteresis (cooling)
Hysteresis (cooling)
Control period (heating)
Control period (heating)
Number of send data words
(Undefined) Unit No.
Number of units
(Undefined) Unit No.
Control period (cooling)
Control period (cooling)
