E5ZE Temperature Controller Write Protocol Appendix I
Write Proportional Band, Integral Time, and Derivative Time
(Sequence No. 152 (Hex 0098))
Writes the proportional bands (constant P), integral times (constant I), and derivative times (constant D).
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
001A (0026 decimal) (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
+2 Channel 0
Constant P (4 digits BCD)
0000 to 9999
+3 Channel 0
Constant I (4 digits BCD)
0000 to 3999
+4 Channel 0
Constant D (4 digits BCD)
0000 to 3999
•
•
•
+23 Channel 7
Constant P (4 digits BCD)
0000 to 9999
+24 Channel 7
Constant I (4 digits BCD)
0000 to 3999
+25 Channel 7
Constant D (4 digits BCD)
0000 to 3999
First word of
send data
Number of send data words
+0
+1
+2
+3
+4
+23
+24
+25
(Undefined) Unit No.
Constant P
~ ~
Constant I
Channel 0
Channel 7
Constant D
Constant P
Constant I
Constant D
