Omron Sysmac CP1H User Manual

Counters
4-axis differential phase control is
a standard feature.
Counters
4-axis differential phase control is
a standard feature.
Serial Communications
Two ports supporting both RS-232C and RS-485.
Serial Communications
Two ports supporting both RS-232C and RS-485.
Pulse Outputs
Four axes are standard features.
Pulse Outputs
Four axes are standard features.
32
With accelerating globalization and the diversification of market needs, added value is being
sought in equipment as never before. The need for enhanced functionality, handling of
advanced systems, and improved ease of maintenance and reliability make this a complex
matter. OMRON’s latest solution is the release of a new package-type terminal-block PLC
that combines full basic functionality with advanced expandability.
A full complement of built-in functions enables increased applicability.
Reducing the design time required for expanded and more complex programming helps
in giving added value to equipment.
OMRON’s PLC Lineup
From large-scale to small-
scale control, programs
can be created
incorporating function
blocks (FB) and structured
text (ST) using the same
instructions and with the
same easy operation.
Building-block PLCs
CS Series
Flexible Package PLCs
CJ Series
All-in-on Package PLCs
CP Series
A New All-in-one Package Controller
with Condensed Multi-functionality
in a New Black Body
A Choice of Three Basic CP1H CPU Units Lets You
Select the Functions You Need.
USB Peripheral Port
Another standard feature.
Built-in Analog I/O
XA CPU Units provide 4 input words and 2 output words.
USB Peripheral Port
Another standard feature.
Built-in Analog I/O
XA CPU Units provide 4 input words and 2 output words.
Small-scale Control
Large-scale Control
High-speed Positioning
CP1H-Y CPU Units
Pulse Outputs for 4 Axes
High-speed Counters
for 4 Axes
Built-in Analog I/O
Serial Communications
Two axes at 100 kHz and two axes at 30 kHz
Four axes at 100 kHz for signal-phase
(50 kHz for differential phases)
Four analog inputs and
two analog outputs
Two axes for 1 MHz and two axes for 30 kHz
Two axes at 1 MHz for single-phase (500 kHz for
differential phases) and two axes at 100 kHz for
single-phase (50 kHz for differential phases)
RS-232C
Option Board
RS-422A/485
Option Board
Up to two Option Boards can be mounted.
Built-in Analog I/O
CP1H-XA CPU Units
Standard
CP1H-X CPU Units
To be released
soon.
( )
