Omron SYSMAC NX-CIF Series - 9 Troubleshooting

9 - 1
9
NX-series Communications Interface Units User’s Manual (W540)
This section describes the error information and corrections for errors that can occur
when the CIF Units are used.
9-1 How to Check for Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-2
9-2 Checking for Errors with the Indicators
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3
9-3 Checking for Errors and Troubleshooting on the Support Software . . . . 9-4
9-3-1 Checking for Errors from the Sysmac Studio . . . . . . . . . . . . . . . . . . . . . . . . . . 9-4
9-3-2 Checking for Errors from Support Software Ot
her Than the Sysmac Studio . . 9-5
9-3-3 Event Codes for Errors and Troubleshooting Procedures . . . . . . . . . . . . . . . . 9-6
9-4 Resetting Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-20
9-5 Troubleshooting Flowchart . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . 9-21
Troubleshooting
