Section 2 Antennas with Separate Amplifier
Section 2
Specifications and Performance
• V680-HS63-R
Antenna
23
5
5
40
28±0.1
53
27 6
11
(Unit: mm)
Operation indicator
Note: Mounting Hole Dimensions
Coil center
Two, M4 or 4.5 dia. holes
5030
16.5 dia.
Coaxial cable, 5.3 dia.,
standard length: 2 m
Insulation cover
(39.5)
Connector
Ferrite core
16.5 dia.
14.5 dia.
Case material ABS resin
Fill resin Epoxy resin
Cable PVC (black)
