Omron V680 - Specifications

26
Section 2 Amplifier
RFID System
User's Manual
Section 2
Specifications and Performance
Cables
 Specifications
 Dimensions
Item Model V700-A43/V700-A44
Number of conductors 10
Insulation resistance 5 MΩ min. (at 500 VDC) between terminals and sheath
Dielectric strength 500 VAC, 1 min
Item Model V700-A43 V700-A44
Length (L1) Approx.10m Approx. 20 m
Weight Approx. 700 g Approx.1,350 g
51 L1 ±100 49
15.5 dia.
Connector (Controller end))
Connection label
Connector (Amplifier end)
6 dia.
15 dia.
(Unit: mm)
Casing material PVC
