39
RFID System
User's Manual
Section 3 Communications Distances
Section 3
Communications Specifications
 Communications Area (Reference)
(Unit: mm)
Read
Write
(Unit: mm)
Read
Write
V680-HS52 and V680-D1KP66MT
with Metal on Back Surface (Steel)
V680-HS63 and V680-D1KP66MT
with Metal on Back Surface (Steel)
−50 −40 −30 −20 −10 0 10 20 30 40 50
0
10
20
30
40
50
60
Y
X
−50 −40 −30 −20 −10 0 10 20 30 40 50
0
10
20
30
40
50
60
Y
X
(Unit: mm)
Read
Write
V680-HS65 and V680-D1KP66MT
with Metal on Back Surface (Steel)
−100 −80 −60 −40 −20 0 20 40 60 80 100
0
20
40
60
80
100
120
Y
X
