Omron V680 - Page 56

54
Section 4 Installing Tags
RFID System
User's Manual
Section 4
Installation
 Influence of Angle (Reference)
Install Antennas and Tags as close to parallel to each other as possible. Communications are possible
even when an Antenna and a Tag are mounted at an angle, but the communications distance will be
shortened. The relation between the angle and the communications distance is shown below.
 Percentage Drop in Communications Distance According to Angle of V680-D1KP52MT
• V680-HS52 and V680-D1KP52MT • V680-HS63 and V680-D1KP52MT
• V680-HS52 and V680-D1KP52MT (Metal: Steel)
0
10
20
30
40
50
60
70
80
90
100
0 1020304050607080
(%)
V680-HS52 and V680-D1KP52MT
0
10
20
30
40
50
60
70
80
90
100
0 1020304050607080
V680-HS63 and V680-D1KP52MT
V680-HS52 and V680-D1KP52MT
0
10
20
30
40
50
60
70
80
90
100
0 1020304050607080
Reduction in maximum communications distance
Tag angle
(Metal: Steel)
( )
(%)
Reduction in maximum communications distance
Tag angle
( )
(%)
Reduction in maximum communications distance
Ta
g
an
g
le
( )
Antenna
Tag
Non-metallic material
Tag
Non-metallic
material
Antenna
Non-Metallic material
Antenna
Tag
Steel
