Frequency Inverters
Type Designation
200 V class
400 V class
Specifications
IP20 Single-phase: CIMR-V7AZ
B0P1 B0P2 B0P4 B0P7 B1P5 B2P2 B4P0
IP65 Single-phase: CIMR-V7TZ
--- --- B0P405 B0P705 B1P505 B2P205 ---
IP20 Three-phase: CIMR-V7AZ
20P1 20P2 20P4 20P7 21P5 22P2 24P0
Maximum permissible motor output kW
1
1. Based on a standard 4-pole motor for maximum applicable motor output. Select the inverter model within the allowable motor rated current
0.12 0.25 0.55 1.1 1.5 2.2 4.0
Output
characteristics
Inverter capacity kVA
0.3 0.6 1.1 1.9 3.0 4.2 6.7
Rated output current A
0.8 1.6 3.0 5.0 8.0 11.0 17.5
Max. output voltage
Proportional to input voltage: 0..240 V
Max. Output frequency
400 Hz
Power
Supply
Rated input voltage
and frequency
Single-phase 200..240V 50/60 Hz
3-phase 200..230V 50/60 Hz
Allowable Voltage
Fluctuation
-15%..+10%
Allowable Frequency
Fluctuation
+5%
IP20 Three-phase: CIMR-V7AZ
40P2 40P4 40P7 41P5 42P2 43P0 44P0 45P5 47P5
IP65 Three-phase: CIMR-V7TZ
40P405 40P705 41P505 42P205 43P005 44P005
Maximum permissible motor output kW
1
1. Based on a standard 4-pole motor for maximum applicable motor output. Select the inverter model within the allowable motor rated current
0.37 0.55 1.1 1.5 2.2 3.0 4.0 5.5 7.5
Output
characteristics
Inverter capacity kVA
0.9 1.4 2.6 3.7 4.2 5.5 7.0 11.0 14.0
Rated output current A
1.2 1.8 3.4 4.8 5.5 7.2 9.2 14.8 18.0
Max. output voltage
Proportional to input voltage: 0..400 V
Max. Output frequency
400 Hz
Power
Supply
Rated input voltage
and frequency
3.phase 380..460 VAC, 50/60 Hz
Allowable Voltage
Fluctuation
-15%..+10%
Allowable Frequency
Fluctuation
+5%
Voltage
B: Single-phase 200VAC
2: Three-phase 200VAC
4: Three-phase 400VAC
Z: European standard specifications
Inverter
V7 series
A: With digital operator (with potentiometer)
T: V7 IP65 type with digital operator
( without potentiometer )
CIMR—V7AZB0P10
Max. Applicable Motor Output
0P1: 0.1 kW
7P5: 7.5 kW
~
"P" indicates a decimal
point
[ ]
Protective Enclosure:
0: IP20
1: NEMA1
05: IP65
