OMS ARCADIA EXT S.T.01/3R ED.0 REV.8 09/2020
54
Other fuses are inside the protective cover on the armchair electronic card.
The protective cover can be removed by unscrewing the screws (D) and (G), the cover (F) covering the screw
(G) will simply be removed by pulling it out.
Chair board
F1 10AT, 32 Vdc
A series of spare fuses supplied by O.M.S. are located inside the accessory box.
The replacement of the fuses must done by an authorized technician O.M. S.
