Omtech K40+ User Manual

33
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
Label
—
—
E
X
Y
Z
E
X
Y
Z
PWR
BLOW
5V
IN1 & IN2
TH5
TH3 & TH4
TH1 & TH2
HE1
HE2
FAN
X & Y
Out1 & Out2
Z
Pins
4
8
5
5
5
5
4
4
4
4
4
2
2
3
2
3
3
2
2
2
5
4
3
Use
USB Type B Computer Connection
MicroSD Card Firmware & Config File Storage
Multiphase U Axis Driver Signal
Multiphase X Axis Driver Signal
Multiphase Y Axis Driver Signal
Multiphase Z Axis Driver Signal
OMTech or Bipolar U Axis Driver Signal
OMTech or Bipolar X Axis Driver Signal
OMTech or Bipolar Y Axis Driver Signal
OMTech or Bipolar Z Axis Driver Signal
Main Power Connection
Air Assist Signal (5V)
5V Power Output
5V Input Connections
5V Temp. Sensor Connection
5V Temp. Sensor Connections
5V Temp. Sensor Connections
5V Temp. Controller Signal
5V Temp. Controller Signal
5V Add-On Exhaust Signal
X & Y Axis Limit Switches
5V Output Signals
Z Axis Limit Switch

Omtech K40+ Specifications

General

Laser Power	40W
Positioning Accuracy	0.01 mm
Repeat Positioning Accuracy	0.01 mm
Interface	USB
Working Area	300 x 200 mm
Software Compatibility	CorelDraw
Operating Temperature	35°C
Power Supply	AC 110V
Supported File Formats	BMP
Laser Type	CO2
