Supplemental Information
105
N300 WiFi ADSL2+ Modem Router (N300RM)
Technical Specifications
Table 5. Technical specifications
Feature Description
Data and routing protocols TCP/IP, RIP-1, RIP-2, DHCP, PPPoE or PPPoA, RFC 1483 Bridged or
Routed Ethernet, and RFC 1577 Classical IP over
ATM
AC plug is localized 110V-220V, 50/60 Hz, input
Dimensions 200 x 113.4 x 86.2 mm (7.9 x 4.5 x 3.4 in.)
Weight 0.2.85 kg (0.63 lb)
Operating temperature 0 to 40 C (32º to 104º F)
Operating humidity 90% maximum relative humidity, noncondensing
Regulatory compliance EN 55022/24 (CISPR 22/24) Class B
EN 60950 (CE LVD) Class B
EN 301 489-17 V.2.1.1 (2009)
EN 301 489-1 V1.9.2 (2011)
EN 300 328 V1.7.1 (2006)
K21:ITU-T K.21- 07/2003
TBR21: TBR21 January 1998
Interface specifications LAN: 10BASE-T or 100BASE-Tx, RJ-45
WAN: ADSL, dual RJ-11, pins 2 and 3
T1.413, G.DMT, G.Lite
ITU Annex A hardware or Annex B hardware
ITU G.992.5 (ADSL2+)
