3-3
CHECKING ENGINE OIL LEVEL
Park the vehicle on level ground and shut off the
genset before checking the engine oil level.
WARNING
Crankcase pressure can blow hot
engine oil out the fill opening causing severe
burns. Always stop the genset before removing
the oil fill cap.
1. Unscrew the oil fill cap and wipe oil off the dip-
stick (Figure 3-1). Screw the cap back on, re-
move it and check the oil level on the dip stick.
2. Add or drain oil as necessary. See ENGINE OIL
RECOMMENDATIONS (Page 2-1). Keep the
oil level between the FULL and ADD marks.
The oil fills slowly because it takes time for the
air in the crankcase to escape. Recheck the
level in a few minutes to make sure.
CAUTION
Too much oil can cause high oil
consumption. Too little oil can cause severe
engine damage. Keep the oil level between
the FULL and ADD marks.
3. Screw the oil fill cap back on securely.
LPG SLUDGE DRAIN VALVE
(CLOSED POSITION)
OIL FILL
CAP/DIPSTICK
OIL DRAIN
VALVE
FIGURE 3-1. OIL FILL/DIPSTICK AND DRAIN VALVE
