4-7
RAW WATER IN
EXHAUST & RAW
WATER OUT
HOSE BARB TO CONNECT
COOLANT RECOVERY TANK
THERMOSTAT
HOUSING
COOLANT
PUMP
BLOCK
DRAIN CAP
RAW WATER
PUMP
COOLANT
RA W WA TER
EXHAUST
MANIFOLD &
COOLANT
RESERVOIR
EXHAUST-WATER
MIXER WITH HIGH
TEMPERATURE
EXHAUST SWITCH
COULD BE
CONNECTED TO
EXTERNAL SIPHON
BREAK AT THIS
POINT—SEE
INSTALLATION
MANUAL
RAW WATER
FLOW SENSOR
HEAT EXCHANGER
CLEANOUT COVER
PRESSURE CAP &
COOLANT FILL NECK
FIGURE 4-4. ENGINE COOLING SYSTEM
Redistribution or publication of this document,
by any means, is strictly prohibited.
