12-1
12. Specifications
GENERATOR: 2-Bearing, 2-Pole Rotating Field, Microprocessor Regulated. Rating on Genset Nameplate
FUEL CONSUMPTION:
60 Hz: Full Load
Half Load
0.60 gph (2.3 liter/hr)
0.35 gph (1.3 liter/hr)
50 Hz: Full Load
Half Load
0.50 gph (1.9 liter/hr)
0.29 gph (1.1 liter/hr)
Engine/Generator Speed: 60 Hz
50 Hz
2900/3600 rpm
2400/3000 rpm
ENGINE: 4-Stroke Cycle, Indirect Injection Diesel, Water Cooled, Microprocessor Governed (Isochronous)
Number of Cylinders 2
Bore 2.52 inch (64 mm)
Stroke 2.45 inch (62.2 mm)
Displacement 24.41 inch
3
(400 cm
3
)
Compression Ratio 23:1
Firing Order (Clockwise Rotation) 1-2
Fuel Injection Timing 18° – 20° BTDC
Fuel Injection Pressure 1991 psi (13.73 MPa)
Valve Lash (cold)
0.0059 – 0.0073 INCH (0.145 – 0.185 MM)
Engine Oil Capacity 2.2 quart (2.1 liter)
Engine Oil Drain Connection 3/8 NPT
Coolant Capacity 2.2 quart (2.1 liter)
Coolant Flow: 60 Hz
50 Hz
3.5 gpm (13 liter/min)
3.0 gpm (16 liter/min)
Raw Water Flow: 60 Hz
50 Hz
5.0 gpm (19 liter/min)
4.0 gpm (15 liter/min)
Maximum Raw Water Pump Lift 4 feet (1.2 m) with 5/8 inch ID hose
Raw Water Inlet Connection 5/8 inch (15.9 mm) ID Hose
Maximum Fuel Pump Lift 4 feet (1.2 m) with 3/8 inch ID fuel line
Recommended Fuel Line Size 3/8 inch (9 mm) ID
Fuel Supply Connection 1/8 NPT female
Fuel Return Connection 1/8 NPT female
Maximum Exhaust Back Pressure
3 INCH (76 MM) HG
Wet Exhaust Outlet Connection
2.0 INCH (50.8 MM) ID HOSE
Combustion Air
18 CFM (30 M
3
/HR)
Generator Cooling Air
60-80 CFM (100-135 M
3
/HR)
BATTERIES:
Nominal Battery Voltage 12 volts
Minimum CCA Rating 360 amps
Battery Charging Output Trickle (3 amps)
SIZE, WEIGHT, NOISE:
Size: L x W x H 26 x 20.1 x 20.6 inch (662 x 511 x 524 mm)
Weight (dry) 350 lbs (159 kg)
Noise: 60 Hz
50 Hz
71 dB(A)
68 dB(A)
