5-3
DRIP
PAN
VIBRATION
ISOLATION
MOUNT (3)
FRONT ENGINE
SUPPORT BRACKET
RUBBER NOISE
PLUGS
GENERATOR END
BELL SUPPORT
BRACKET
FIGURE 5-2. DRIP PAN AND MOUNTING SYSTEM
