8-2
STATOR
THROUGH
BOLTS (4)
ROTOR
O-RING
BRUSH BLOCK
ASSEMBLY
WAVE WASHER
END BELL
ENGINE-GENERATOR
ADAPTER
O-RING
END BELL
SUPPORT BRACKET
FAN
SLIP RINGS
LEADS,
GROMMET
& CLIP
NOTE: ON SKEWED STATORS,
(STRAIGHT STATOR SHOWN) THE
THROUGHBOLTS MUST COME
THROUGH THE SLOTTED RATHER
THAN ROUND HOLES FOR
PROPER ALIGNMENT OF END
BELL, STATOR AND ADAPTER.
FIGURE 8-1. GENERATOR
