9-2
GENSET
CONTROLLER
BATTERY
CHARGING
REGULATOR A1
WITH HEAT SINK
2-POLE CIRCUIT
BREAKER
CB3
CONTROL
SWITCH
S4
EMERGENCY
SWITCH CB1
HOUR
METER
M11
CONNECTORS
P1, P2 & P3
OPTIONAL NIM WITH
CONNECTOR HARNESS
RELAYS
K3 AND K4
FIGURE 9-1. GENSET CONTROLLER AND ITS MOUNTING
