OneTouch ULTRA2 User Manual

2
GETTING TO KNOW YOUR SYSTEM
Getting to know your system
TEST STRIP
Edge to
apply sample
Conrmation
window
Contact bars
Insert into test port
METER
Display
mg/dL is the pre-set
unit of measure
Up and down buttons
Select or change information
Indicates selection available
using up or down button
Test port
Insert test strip here to
turn meter on for testing
OK button
Turns the meter on/o
Turns the backlight on/o
Conrms menu selections

OneTouch ULTRA2 Specifications

Power

meter power source	One replaceable 3.0 Volt CR 2032 lithium battery
backlight power source	One replaceable 3.0 Volt CR 2032 lithium battery
battery ratings	2 x 3.0 V d.c., 60 mA

Operating Environment

temperature range	6–44°C
relative humidity range	10–90%
altitude range	up to 3048 metres

Weight and Dimensions

weight	42.5 grams
size	7.92 x 5.72 x 2.29 cm
