4
The fittings on these pool pumps are constructed of ABS. Some PVC jointing
compounds are incompatible with ABS possibly causing failure to the product.
Check compound suitability prior to use.
All glued fittings and pipe work should be allowed to dry to atmosphere for 24
hours before closing installation. Failure to do so could cause injury or instal-
lation failure.
Barrel Unions are to be hand tightened ONLY, to prevent damage occurring
from over-tightening.
Pump Mounting should be:
INSTALLATION
1) Pump position must be: Solid - Level - Rigid - Vibration Free
2) Allow pump suction inlet height to be as close to water level as possible.
3) Allow for use of a piece of short, straight suction pipe into the suction port
of the pump (minimum length for 40mm diameter suction = 160mm; 50mm
diameter suction = 200mm) in order to minimise water turbulence entering
the pump.
!!
!!
!
