REMOVAL OF PUMP FOR SERVICING
Switch off power and remove plug from power point, if the pump is hard wired into
any other controls such as time clocks or automatic heads etc., THE WIRING
SHOULD BE REMOVED BY A QUALIFIED ELECTRICIAN.
Close control valves and undo barrel unions from suction and discharge lines.
Remove pump and take to your nearest authorised Onga service agent or call:
1800 664 266 (Australia)
0800 664 269 (New Zealand)
If the need arises to contact an Onga service agent please have all details avail-
able including model and serial number, date of purchase and particulars of
fault.
If service parts are required please quote Model Number and Type of pump
as shown on the label of the pump.
Item
No.
Description Qty. Item
No.
Description Qty.
1
Motor 1
9
Basket - Strainer 1
2
Baffle 1
10
O’ring - Lid 1
3a
Mechanical Seal 1
11
Lid & O’ring Assy. 1
3b
O’ring – Casing 1
12
Clacker Assembly 1
3c
Shaft Sleeve & O’ring 1
13
O’ring – Barrel Union 2
4
Diffuser 1
14
Barrel Union Assy. 1
5
Impeller 1
15
Barrel Union Complete 1
6
Casing & Bowl Assy. 1
16 / 17
Bolts & Nuts 4
7
Plug – Drain 1
18
Base & Screws 1
8
Finger Guard 1
