REMOTE OVERVIEW
OPERATIONS
1. Open back cover and put 2 Nos. AAA size alkaline batteries.
2. Short one RESET piece after changing the batteries.
3. The remote signal can be reached up to six meters from the indoor unit.
4. When the button is pressed on remote, indoor unit will “beep” once, indicating
the receipt of signal. If no “beep” sound is heard, press the button once again.
5. Remove batteries if remote control has not been used for long time.
6. “*” Available in selected models only.
MODE H.SWING V.SWING
SLEEP
i-COOL
TIMERFAN
TURBO
LOCK
SLEEP
HORIZONTAL SWING
VERTICAL SWING
LOCK / UNLOCK
i-COOL
BACK VIEW
RESET
CLOCK *
Operating Your Air Conditioner:
Your Split Air Conditioner can be conveniently operated using the intelligent cordless
remote control.
1. Switch on the MCB.
Press ON/OFF button on remote handset to switch ON the AC.
Your AC switches on with parameters that were set before power was switched
off. The unit receives the signal with "BEEP" tone and your AC starts operation.
Time Delay: To protect the compressor, a time delay is incorporated in the circuit.
The Time Delay ensures that the compressor switches ON only after a delay of about 3
minutes.
2. Press the Auto, Cool, Dry, or Fan mode by pressing “MODE" button.
3. Press the "FAN” button to set the fan speed.
Each press changes the fan speed from
Auto-High-Med-Low Fan speed.
The selected fan setting symbol can be
seen on the LCD.
4. The Set Temp. is displayed on LCD.
5. To switch off the AC, press the
same ON/OFF Button.
Setting the Desired Room Temp.:
You can set the temp. at which you would like your room to be.
O
Press " " button to increase the set temp. On every press, the temp. increases by 1 C.
O
Press " " button to decrease the set temp. On every press, the temp. decreases by 1 C
The two digit display shows the changing set temp. on LCD
O
The setting temp. range is from 16- 32 C.
