Onkyo CR-315

57
Specifications
Specifications and features are subject to change without notice.
General
CR-515 CR-315
Power Supply: AC 230 V, 50 Hz AC 220–230 V, 50/60 Hz AC 120 V, 60 Hz
Power Consumption: 56 W North American: 60 W Others: 56 W
Stand-by Power Consumption: 0.25 W North American: 0.15 W Others: 0.25 W
Dimensions (W
×
H
×
D): 205 × 116 × 353 mm (8-1/16" × 4-9/16" × 13-7/8") 205 × 116 × 352.5 mm (8-1/16" × 4-9/16" × 13-7/8")
Weight: 4.3 kg (9.5 lbs.) 4.2 kg (9.3 lbs.)
Audio Inputs
Digital Inputs: 1 (optical) 0
Analog Inputs: 4 (LINE1, LINE2, DOCK, TAPE) 3 (LINE, DOCK, TAPE)
Audio Outputs
Analog Outputs: 2 (DOCK, TAPE) 1 (TAPE)
Subwoofer Pre Outputs: 1 1
Speaker Outputs: 2 2
Phones: 1 1
Amplifier Section
CR-515 CR-315
Power Output:
European: 2ch
× 20 W (4 Ω , 1 kHz, 2ch driven,
IEC)
Asian: 19 W + 19 W (8
Ω , 1 kHz, JEITA)
26 W + 26 W (4
Ω , 1 kHz, JEITA)
North American: 14 W + 14 W (8
Ω , 1 kHz, FTC)
19 W + 19 W (4
Ω , 1 kHz, FTC)
European: 2ch
× 19 W (4 Ω , 1 kHz,
2ch driven, IEC)
Asian:
18 W + 18 W (8 Ω , 1 kHz, JEITA)
25 W + 25 W (4
Ω , 1 kHz, JEITA)
Dynamic Power: 22 W + 22 W (3 Ω , Front)
20 W + 20 W (4
Ω , Front)
14 W + 14 W (8
Ω , Front)
22 W + 22 W (3
Ω , Front)
20 W + 20 W (4
Ω , Front)
14 W + 14 W (8
Ω , Front)
THD (Total Harmonic Distortion): 0.4% (1 kHz, 1 W) 0.9% (Power Rated) 0.4% (1 kHz, 1 W)
Damping Factor: 25 (Front, 1 kHz, 8
Ω ) 25 (Front, 1 kHz, 8 Ω )
Input Sensitivity and Impedance: 150 mV/50 k
Ω (TAPE) 150 mV/50 k Ω (TAPE)
Output Level and Impedance: 150 mV/2.2
Ω (REC OUT) 150 mV/2.2 Ω (REC OUT)
Frequency Response: 10 Hz–100 kHz/±3 dB (TAPE) 10 Hz–100 kHz/±3 dB (TAPE)
Tone Control: ±6 dB, 80 Hz (BASS)
±8 dB, 10 kHz (TREBLE)
+7 dB, 80 Hz (S.BASS)
±6 dB, 80 Hz (BASS)
±8 dB, 10 kHz (TREBLE)
+7 dB, 80 Hz (S.BASS)
Signal to Noise Ratio: 100 dB (LINE, IHF-A) 100 dB (LINE, IHF-A)
Speaker Impedance: 4
Ω –16 Ω 4 Ω –16 Ω
Tuner Section
CR-515 CR-315
FM
Tuning Frequency Range: 87.5 MHz–108.0 MHz North American: 87.5 MHz–107.9 MHz
Others: 87.5 MHz–108.0 MHz
Usable Sensitivity: Stereo: 22.2 dBf (IHF) Mono: 15.2 dBf (IHF) Stereo: 22.2 dBf (IHF) Mono: 15.2 dBf (IHF)
Signal to Noise Ratio: Stereo: 67 dB (IHF-A) Mono: 73 dB (IHF-A) Stereo: 67 dB (IHF-A) Mono: 73 dB (IHF-A)
THD (Total Harmonic Distortion): Stereo: 0.5% (1 kHz) Mono: 0.3% (1 kHz) Stereo: 0.5% (1 kHz) Mono: 0.3% (1 kHz)
Stereo Separation: 40 dB (1 kHz) 40 dB (1 kHz)
AM
Tuning Frequency Range: 522 kHz–1611 kHz North American: 530 kHz–1710 kHz
Others: 522 kHz–1611 kHz
Usable Sensitivity: 300 dBf (30 µV) 300 dBf (30 µV)
Signal to Noise Ratio: 40 dB 40 dB
THD (Total Harmonic Distortion): 0.7% 0.7%
CD
CR-515
CR-315
Frequency Response: 4 Hz–20 kHz 10 Hz–20 kHz
Audio Dynamic Range: 96 dB 95 dB
THD (Total Harmonic Distortion): 0.005% 0.009%
Wow and Flutter: Below threshold of measurability Below threshold of measurability
Audio Output/Impedance (Analog): 1.3 V/1.0 k
Ω 1.3 V/1.0 k Ω
