CR-315/315DAB
SERVICE PROCEDURE-1
PROTECTION OF EYES FROM LASER BEAM DURING SERVICING
This set employs a laser. Therefore, be sure to follow carefully
the instructions below when servicing.
WARNING!!
SERVICE WARNING : DO NOT APPROACH THE
LASER EXIT WITH THE EYE TOO CLOSELY.
IN CASE IT IS NECESSARY TO CONFIRM LASER
BEAM EMISSION, BE SURE TO OBSERVE FROM
A DISTANCE OF MORE THAN 30cm FROM THE
SURFACE OF THE OBJECTIVE LENS ON THE
OPTICAL PICK-UP BLOCK.
Laser Diode Properties
Material: GaAS/GaALAs
Wavelength: 780nm
Laser output: max. 0.5mW*
Emission Duration: continuous
*This output is the value measured at a distance about 1.8mm
from the objective lens surface on the Optical Pick-up Block.
LASER WARNING LABEL
The label shown below are affixed.
1. Warning label
2. Class 1 label
"CLASS 1 LASER
PRODUCT"
LUOKAN 1
LASERLAITE
KLASS 1
LASER APPARAT
SERVICE PROCEDURE
1. Replacing the fuses
This symbol located near the fuse indicates that the
fuse used is show operating type, For continued protection against
fire hazard, replace with same type fuse , For fuse rating, refer to
the marking adjest to the symbol.
Ce symbole indique que le fusible utilise est e lent.
Pour une protection permanente, n'utiliser que des fusibles de meme
type. Ce demier est indique la qu le present symbol est apposre.
REF.NO.
F901
F901
F901
F901
F901
F901
PART NAME
FUSE
FUSE
FUSE
FUSE
FUSE
FUSE
DESCRIPTION
0.5A-SE-EAWK
1.25A-T/UL-ST2
0.5A-SE-EAWK
1.25A-T/UL-ST2
0.5A-SE-EAWK
0.5A-SE-EAWK
PART NO
252063GR
252251GR
252063GR
252251GR
252063GR
252063GR
<Notes>
<MPP> : CR-315 European model
<MDC> : CR-315 Canadian model
<MGT> : CR-315 Asian model
<MDT>: CR-315 Taiwanese model
<MGQ> : CR-315 Hong kong model
<DAB MPB> : CR-315DAB British model
REMARK
!, <MPP>
!, <MDC>
!, <MGT>
!, <MDT>
!, <MGQ>
!, <DAB MPB>
