1/22 PAGE
CR-315/315DAB
<Note>
Parts marked by "NSP" are generally unavailable because
they are not in our Master Spare Parts List.
<Notes>
(B) : Black model
(S) : Silver model
<MPP> : CR-315 European model
<MDC> : CR-315 Canadian model
<MGT> : CR-315 Asian model
<MDT>: CR-315 Taiwanese model
<MGQ> : CR-315 Hong kong model
<DAB MPB> : CR-315DAB British model
EXPLODED VIEW PARTS LIS
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
EV
A001 F BRACKET (B) 1 27111462 (B)
EV
A001 F BRACKET (S) 1 27111461 (S)
EV
A004 SCREW 3TTB+8B(CU)SR 9 801618
EV
A007 SCREW 3TTB+8B(CU)SR 2 801618
EV
A009 CHASSIS --- 1 --- NSP
EV
A101 REAR PANEL CR-315 MPP 1 27123605 <MPP>
EV
A101 REAR PANEL CR-315 MDC 1 27123609A <MDC>
EV
A101 REAR PANEL CR-315 MPP 1 27123605 <MGT>
EV
A101 REAR PANEL CR-315 MPP 1 27123605 <MDT>
EV
A101 REAR PANEL CR-315 MPP 1 27123605 <MGQ>
EV
A101 REAR PANEL CR-315DAB MPB 1 27123606 <DAB MPB>
EV
A102 HOLDER KGLS-6RT 6 27190693A
EV
A103 SCREW 3TTB+8B(3BC) 14 838430088GR <MPP>
EV
A103 SCREW 3TTB+8B(3BC) 15 838430088GR <MDC>
EV
A103 SCREW 3TTB+8B(3BC) 14 838430088GR <MGT>
EV
A103 SCREW 3TTB+8B(3BC) 14 838430088GR <MDT>
EV
A103 SCREW 3TTB+8B(3BC) 14 838430088GR <MGQ>
EV
A103 SCREW 3TTB+8B(3BC) 14 838430088GR <DAB MPB>
EV
A104 HOLDER KGPS-6RF 3 27191112
EV
A105 HOLDER KGLS-12RT 3 27190266
EV
A106 HOLDER (PWB) 1 27191280A
EV
A107 WASHER --- 1 870191 <DAB MPB>
EV
A108 NUT --- 1 800562 <DAB MPB>
EV
A109 COVER (HT) 1 28184981A
EV
A110 SCREW 3TTB+8B(3BC) 2 838430088GR
EV
A112 SCREW 3TTB+8B(CU)SR 4 801618
EV
A113 HEAT SINK 173 1 27160513-1
EV
A115 SCREW 3SMS8W.SW+14B(CU) 4 801634
EV
A117 SCREW 3TTB+8B(CU)SR 4 801618
EV
A119 LEG (AS) 2 27175253-1B
EV
A121 SCREW 3TTB+8B(3BC) 2 838430088GR
EV
A123 SCREW 4TTC+6C(3BC) 4 830440069GR
EV
A125 TAPE TAPE(CLOTH-16U) (1) 29110083
EV
A127 SHLD PLT (AMP) 1 27150510
EV
A128 SHLD PLT (SP) 1 27150511
EV
A130 ISO PLT (ST) 1 28175326
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
