CR-315/315DAB
EXPLODED VIEWS OF MECHANISM-1
CD MECHANISM : DLM1A01-14CA / KSM-213CLCM
Z005
Z006
Z007
x 4 pcs.
Z009 (gold)
x 2 pcs.
Z010
x 4 pcs.
Z008 (silver)
x 2 pcs.
PARTS LIST
PART NO. (SN) PART NAME
24800056
24800017
24818058
24820071
24820072
801632
Tray loading unit : DLM1A01-14CA
Refer to "EXPLODED VIEWS OF MECHANISM-2"
Drive unit : KSM-213CLCM
Refer to "EXPLODED VIEWS OF MECHANISM-3"
Q'TY
Front side
CD Tray Loading unit
CD Drive unit
INSULATOR
SPRING
SPRING
SCREW
DLM1A01-14CA
KSM-213CLCM
(CDC-A)
TP-D (silver)
TP-E (gold)
2.6 x 8 x W10
1
1
4
2
2
4
DESCRIPTION
<Note>
CD MECHANISM =
Tray loading unit : "DLM1A01-14CA"
+ Drive unit : "KSM-213CLCM"
REF. NO.
Z005
Z006
Z007
Z008
Z009
Z010
