Onkyo CR-315 Service Manual

CR-315/315DAB
EXPLODED VIEWS OF MECHANISM-2
CD TRAY LOADING UNIT : DLM1A01-14CA
4
6
1
3
8
9
5
12
2
11
10
7
PARTS LIST
PART NO. (SN) DESCRIPTION Q'TY
CHASSIS
TRAY
SUB CHASSIS
CAM SLIDER
GEAR TRAY
CLAMPER ASS'Y
PWB ASS'Y
GEAR A
PULLEY GEAR
MOTOR ASS'Y
LOADING BELT
SCREW
65-210-1054
65-218-1055
65-211-2040
65-239-2004
65-222-3005
65-093-4057H
65-093-4058H
65-222-4037
65-222-4004
65-093-4068H
02-083-4274
GSP14A25027
1
1
1
1
1
1
1
1
1
1
1
2
REF. NO.
1
2
3
4
5
6
7
8
9
10
11
12
