Onkyo CR-315 Service Manual

CR-315/315DAB
51
54
55
53
56
57
58
61
52
PARTS LIST
REF. NO. PART NO. (SN) DESCRIPTION
51
52
53
54
55
56
57
58
61
Motor chassis ass'y
Motor gear ass'y
Sled shaft
Gear (A) (S)
P2 x 3, Screw
Leaf switch
Motor PC board
Connector 6pin
KSS-213C, Pickup
EXPLODED VIEWS OF MECHANISM-3
CD DRIVE UNIT : KSM-213CLCM
X-2625-877-1
X2625-769-1
2626-908-01
24810023
7621-255-15
24840008
1639-678-12
1-564-722-11
8848-483-05
Q'TY
1
1
1
1
2
1
1
1
1
OK
NG
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
