En-25
Wireless Playback via Bluetooth—Continued
Some devices may not be able to pair or connect by
touch (NFC). In such a case, try to establish the
connection manually (see page 23).
Do not leave the NFC/Bluetooth-enabled smartphone
or tablet on the NFC mark on the CD receiver. NFC
function will conflict with CD receiver’s operations.
If the Bluetooth Standby function is enabled,
establishing a Bluetooth connection from your
Bluetooth-enabled device will automatically turn on the
power to the CD receiver and Bluetooth will be selected
as the input source.
1
Turn on the power to the CD receiver, then
press the [ ] button to change the input
source to “Bluetooth.
2
Press the [MENU] button, use the [q]/[w]
buttons to select “BT Standby >”, then
press the [ENTER] button.
3
Use the [q]/[w] buttons to select “On”,
then press the [ENTER] button.
The Bluetooth Standby function is now enabled.
To disable the Bluetooth Standby function, select
“Off”, then press the [ENTER] button.
4
Place the CD receiver in standby mode.
Now the CD receiver is in Bluetooth Standby
mode.
Note:
Power consumption during Bluetooth Standby mode
increases compared to normal standby mode.
Some Bluetooth-enabled devices establish a
Bluetooth connection once the power to these devices
is turned on. These devices will automatically turn on
the power to the CD receiver if the Bluetooth Standby
function on the CD receiver is enabled.
If you touch the NFC detection area of your
smartphone or tablet to the NFC mark on the CD
receiver, the power to the CD receiver will be
automatically turned on, and the input source will
switch to Bluetooth, even if the Bluetooth Standby
function is disabled.
Using the Bluetooth Standby
Function

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Onkyo CS-265 and is the answer not in the manual?

Onkyo CS-265 Specifications

General IconGeneral
TypeHome audio mini system
Cassette deckNo
Product colorWhite
Optical disc playerYes
Karaoke-
Impedance6 Ω
Speaker type2-way
Frequency range30 - 22000 Hz
RMS rated power40 W
Woofer diameter100 mm
Tweeter diameter20 mm
Number of speakers2
Signal-to-Noise Ratio (SNR)77 dB
Total Harmonic Distortion (THD)0.1 %
FM band range87.5 - 108 MHz
Supported radio bandsFM
Preset stations quantity30
Display typeLCD
Bluetooth version4.0
Power sourceAC
Input voltage220-240 V
Input frequency50 - 60 Hz
Power consumption (standby)0.4 W
Power consumption (typical)32 W
Weight and Dimensions IconWeight and Dimensions
Depth176 mm
Width130 mm
Height210 mm
Weight1700 g
Package depth281 mm
Package width357 mm
Package height406 mm
Package weight6700 g
Main unit weight1900 g
Main unit dimensions (WxDxH)215 x 273 x 99 mm
