Onkyo CS-265 User Manual

En-35
Specifications
Amplifier
Tuner
CD
USB
Bluetooth
Speakers D-T25
General
■ Audio input
■ Audio output
Specifications and features are subject to change
without notice.
Rated output power
(IEC)
2ch × 20 W (6 Ω, 1 kHz, 2ch driven)
THD + N (total harmonic distortion + N )
10% (Power Rated)
0.1% (1 kHz 1W)
Input sensitivity and impedance
1000 mV/10 kΩ (LINE)
Frequency response 30 Hz - 22 kHz/+3 dB, –3 dB
Tone control +7 dB, –7 dB, 80 Hz (BASS)
+7 dB, –7 dB, 10 kHz (TREBLE)
Signal to noise ratio 77 dB (LINE, IHF-A)
Speaker impedance 6 - 16 Ω
Tuning frequency range 87.50 MHz - 108.00 MHz
Channel presets 30
Signal Readout Optical non-contact
Frequency Response 30 Hz - 20 kHz
THD
(Total Harmonic Distortion)
0.1 %
Wow and Flutter Below threshold of
measurability
Playable media CD and CD-R/CD-RW (music
CDs and MP3 CDs)
Playable media USB Flash Drive (MP3)
iPod/iPhone/iPad
Communication system Bluetooth Specification
version 4.0
Maximum communication
range
Line of sight approx. 10 m (*)
Frequency band 2.4 GHz band (2.4000 GHz -
2.4835 GHz)
Modulation method FHSS (Freq Hopping Spread
Spectrum)
Compatible Bluetooth
profiles
A2DP 1.2 (Advanced Audio
Distribution Profile)
AVRCP 1.5 (Audio Video
Remote Control Profile)
Supported Codec SBC
Transmission range (A2DP)20 Hz - 20,000 Hz (Sampling
frequency 44.1 kHz)
* The actual range will vary depending on factors such as
obstacles between devices, magnetic fields around a
microwave oven, static electricity, cordless phone, reception
sensitivity, antenna’s performance, operating system,
software application, etc.
Type 2 way bass-reflex
Impedance 6 Ω
Maximum input power 40 W
Output sound pressure level82 dB/W/m
Frequency response 80 Hz - 20 kHz
Crossover frequency 10.4 kHz
Cabinet capacity 3.4 liter (0.12 cubic feet)
Dimensions (W × H × D) 130 × 210 × 176 mm
(5-1/8" × 8-1/4" × 6-15/16")
(incl. grille and projection)
Weight 1.7 kg (3.7 lbs.)
Driver units 10 cm (3-15/16") Cone Woofer
2 cm (3/4") Balanced Dome
Tweeter
Terminal Spring Type Color Coded
Other Magnetic shielding
Power supply AC 220 - 240 V, 50/60 Hz
Power consumption 32 W
No-sound power
consumption
5 W
(when not charging iPod/
iPhone/iPad)
Standby power
consumption
0.4 W
(when not charging iPod/
iPhone/iPad)
Dimensions (W × H × D) 215 × 99 × 273 mm
(8-7/16" × 3-7/8" × 10-3/4")
Weight 1.9 kg (4.2 lbs.)
Analog input LINE IN
Speaker Outputs 2 (L/R)
Headphones 1

Onkyo CS-265 Specifications

General

Type	Home audio mini system
Cassette deck	No
Product color	White
Optical disc player	Yes
Karaoke	-
Impedance	6 Ω
Speaker type	2-way
Frequency range	30 - 22000 Hz
RMS rated power	40 W
Woofer diameter	100 mm
Tweeter diameter	20 mm
Number of speakers	2
Signal-to-Noise Ratio (SNR)	77 dB
Total Harmonic Distortion (THD)	0.1 %
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	30
Display type	LCD
Bluetooth version	4.0
Power source	AC
Input voltage	220-240 V
Input frequency	50 - 60 Hz
Power consumption (standby)	0.4 W
Power consumption (typical)	32 W

Weight and Dimensions

Depth	176 mm
Width	130 mm
Height	210 mm
Weight	1700 g
Package depth	281 mm
Package width	357 mm
Package height	406 mm
Package weight	6700 g
Main unit weight	1900 g
Main unit dimensions (WxDxH)	215 x 273 x 99 mm
