Onkyo CS-N755 User Manual

23
Using USB interface/Network Service
To start playback:
Press the Play [1] button.
To stop playback:
Press the Stop [2] button.
To pause playback:
Press the Pause [3] button. The Pause 3 icon appears.
To resume playback, press the Pause [3] button again.
Selecting Music files
To return to the beginning of the music file currently
playing, press the Previous [7] button.
Press the Previous [7] button repeatedly to select
previous file.
• While playback is stopped, pressing the Previous
[7] button will select the previous file.
Press the Next [6] button to select next file.
Random Playback
With random playback, all of the music files are played
in random order.
This mode can only be used while playback is stopped.
Cancelling Random Playback
• To cancel random playback, press the [RANDOM]
button.
• Random playback is cancelled when the USB flash
drive is removed or the
CD receiver is set to Standby.
Select the type of Repeat Playback
When playing back the music files, all files will be
played according to repeat playback. The type of Repeat
playback can be selected.
Note:
Repeat-1 or 1-Folder playback can’t be combined with
random playback.
Displaying Music File Information
You can display various information about the music
files currently playing, including ID3 tags such as title,
artist name, and album name.
•File name
• Folder name
•Title name (if ID3 tag present)
•Artist name (if ID3 tag present)
•Album name (if ID3 tag present)
• Elapsed time
• Total time (the music file currently playing)
• Signal format, sampling rate and bit rate
Controlling Contents of USB Flash
Drive or Network Devices
1
Press the [RANDOM] button.
The random icon appears.
2
To start random playback, press the Play
[1] button.
Press the [REPEAT] button repeatedly to select
the type of repeat playback.
• Repeat playback (default):
Repeat icon appears
• Repeat-1 playback:
Repeats a single selected file.
Repeat-1 icon appears
• 1-Folder playback (USB):
Repeat playback of all files in a selected folder.
Repeat and folder icons appear.
During playback, press the [DISPLAY] button
repeatedly to display the following music file
information.

Onkyo CS-N755 Specifications

General

Karaoke	No
Impedance	4 Ω
Bass reflex	Yes
Speaker type	2-way
Frequency range	10 - 10000 Hz
RMS rated power	44 W
Woofer diameter	120 mm
Tweeter diameter	25 mm
Number of speakers	2
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.4 %
Type	Home audio mini system
Product color	Black, Silver
Number of optical discs	1 discs
Disc types supported	CD, CD-R, CD-RW
Playback disc formats	CD audio
Audio formats supported	AAC, FLAC, MP3, OGG, WAV, WMA
AM band range	522 - 1.611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Internet radio services supported	vTuner
Display type	LCD
Headphone outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Speaker depth	258 mm
Speaker width	154 mm
Speaker height	245 mm
Apple docking compatibility	Not supported
Power source	AC
Input voltage	220-230 V
Input frequency	50 - 60 Hz
Power consumption (standby)	0.26 W
Power consumption (typical)	74 W
Volume control	Rotary

Weight and Dimensions

Depth	331 mm
Width	215 mm
Height	119 mm
Weight	4800 g
