Onkyo DR-UN7

DR-UN7
SERVICE PROCEDURE-2
SERVICE PROCEDURE
Loading No Disc
DVD
DVD Init?
DVD Init??
Waiting LoadingDVD
No Disc
Clear
STANDBY
2. Initialize the unit
(1) Connect the AC power cord to a wall outlet.
(2) Press the STANDBY/ON button.
(3) Set to DVD position by INPUT button.
(4) Press the EDIT/NO/CLEAR button.
(5) Press the MULTI JOG button.
(6) Press the MULTI JOG button.
(7) Press and the hold down the YES/MODE button, then press the STANDBY/ON button.
(8) Disconnect the AC power cord from a wall outlet.
1. Replacing the fuses
This symbol located near the fuse indicates that the
fuse used is show operating type, For continued protection against
fire hazard, replace with same type fuse , For fuse rating, refer to
the marking adjest to the symbol.
Ce symbole indique que le fusible utilise est e lent.
Pour une protection permanente, n'utiliser que des fusibles de meme
type. Ce demier est indique la qu le present symbol est apposre.
REF.NO.
F901
F901 or
F901
F901 or
F901
F901
F901 or
F901
PART NAME
FUSE
FUSE
FUSE
FUSE
FUSE
FUSE
FUSE
FUSE
DESCRIPTION
1.6A-T/UL-ST2
1.6A-UL/T-233
1.6A-T/UL-ST2
1.6A-UL/T-233
0.63A-SE-EAWK
1.6A-T/UL-ST2
1.6A-UL/T-233
0.63A-SE-EAWK
PART NO.
252252GR
252319GR
252252GR
252319GR
252084GR
252252GR
252319GR
252084GR
REMARK
!, <MDD1N>
!, <MDD1N>
!, <MDS4N>
!, <MDS4N>
!, <MGQ3P>
!, <MDT3N>
!, <MDT3N>
!, <MGT3P>
<Notes>
<MDD1N> : USA model
<MDS4N> : South American model
<MGQ3P> : Hongkong model
<MDT3N> : Taiwanese model
<MGT3P> : Southeast agian model
