DVD MECHANISM SECTION PARTS LIST
NO. PART NAME PART NO. DESCRIPTION REMARK N Q'TY
M1 RAIL 4154-6031-2 1
M2 Loading motor assy Q0090C-MOTCC (M2)+(M3) 1
(M2) MOTOR 8913-6002-1 CCM07B-045R1-1A NSP 1
(M3) PULLEY 4154-6001-0 M2*1 NSP 1
M4 SCREW 2900-2604-0000 2.6TTP+4S M1*2 2
M5 TAPE 9500-9006-0 CLOTH-8U 0.03MT 1
M6 RBR BELT 4157-0281-0 DVCP701 1
M7 GEAR 4154-6061-0 (PULLEY) 1
M8 GEAR 4154-6091-0 (A) 1
M9 GEAR 4154-6071-0 (MAIN) 1
M10 GEAR 4154-6101-0 (CAM) 1
M11 SCREW 4135-3301-0 SCREW M7*1,M9*1,M10*1 3
M12 DVD M 24801016 KHM-280AAA 1
M13 CHASSIS 4154-6041-1 (SUB) 1
M14 INSULATOR 4154-6141-0 (A) 2
M15 INSULATOR 4157-0261-0 (B) 2
M16 SCREW 4135-3301-0 SCREW M14*2,M15*2 4
M17 CAP 4154-6161-0 (CHC) 1
M18 YOKE 4135-3201-1 (CHB) 1
M19 MAGNET 4135-3211-0 (CHB) 1
M20 SCREW 2854-3008-0000 3TTB+8B PCB*6 6
M22 TAPE 9500-9007-0 TAPE(CLOTH-16U) M1:0.07:MT 1
M23 SPRING 2510-3591-0 (DV-CP701) 1
M30 TRAY 4154-6011-5 1
M31 BRACKET AS 8901-4650-1 (M) 1
M32 Roulette motor assy Q0090C-MOTPW (M32)+(M33)+(M42) 1
(M32) MOTOR 8913-6003-0 PWN10EA02D NSP 1
(M33) GEAR 4154-6081-0 (WORM) M32*1 NSP 1
(M42) WASHER 4155-0171-0 0.5t*2.1*6 M32*2 NSP 2
M34 SCREW 2900-2003-0000 2P+3F(BC) M31*2 2
M35 GEAR 4154-5991-0 (WHEEL) 1
M36 WASHER 4154-4491-0 (B) M35*1 1
M37 SCREW 2854-3008-0000 3TTB+8B M31*2,PCB*1 3
M38 ROLLER 4154-6131-0 DVCP701 M30*4 4
M39 ROULETTE 4154-6021-1 1
M40 SCREW 4135-3301-0 SCREW M30*1 1
M41 TAPE 9500-9006-0 CLOTH-8U M30:0.03:MT 1
M50 ARM 4154-6051-0 1
M51 CUSHION 4157-0532-0 M50*1,M52*1 2
M52 RETAINER 4135-3881-0 1
M53 SCREW 2854-3008-0000 3TTB+8B M52*1 1
M54 CUSHION 4157-0591-0 M1*2 2
! : Safet
y
p
art
<B> : Black color model
<S> : Silver color model
<CDD1N> : North American area
<CPA4P> : Australian area
Parts marked b
y
"NSP" are
g
enrall
y
unavailable because
they are not in our Master Spare Parts List.
DV-CP702
