U1 DVD Main circuit PC board assy PCB-Q0090C-MPEGA NADG-7807-1A <CDD1N>
U1 DVD Main circuit PC board assy PCB-Q0090C-MPEGB NADG-7807-1A <CPA4P>
U2 Display circuit PC board assy PCB-Q0150C-MAINA NADIS-7808-1
<CDD1N> NSP
U2 Display circuit PC board assy PCB-Q0150C-MAINB NADIS-7808-1B <CPA4P> NSP
(U3) Front disp. PC board assy 1H498508-1A NADIS-7808-1
<CDD1N>
(U3) Front disp. PC board assy 1H498508-1B NADIS-7808-1B <CPA4P>
(U4) Mecha. Control PC board assy 1H498509-1A NADG-7809-1
<CDD1N>
(U4) Mecha. Control PC board assy 1H498509-1B NADG-7809-1B <CPA4P>
(U5) Video output terminal PC board assy 1H498510-1A NAVD-7810-1A <CDD1N>
(U5) Video output terminal PC board assy 1H498510-1B NAVD-7810-1B <CPA4P>
(U6) Audio output terminal PC board assy 1H498511-1A NAAF-7811-1A <CDD1N>
(U6) Audio output terminal PC board assy 1H498511-1B NAAF-7811-1B <CPA4P>
(U7) Disc select switch PC board assy 1H498512-1A NASW-7812-1A <CDD1N>
(U7) Disc select switch PC board assy 1H498512-1B NASW-7812-1B <CPA4P>
(U8) Key operation PC board assy 1H498513-1A NASW-7813-1A <CDD1N>
(U8) Key operation PC board assy 1H498513-1B NASW-7813-1B <CPA4P>
(U9) Standby switch PC board assy 1H498514-1A NASW-7814-1A <CDD1N>
(U9) Standby switch PC board assy 1H498514-1B NASW-7814-1B <CPA4P>
(U10) LED display PC board assy 1H498515-1A NADIS-7815-1A <CDD1N>
(U10) LED display PC board assy 1H498515-1B NADIS-7815-1B <CPA4P>
(U11) Roulette motor PC board assy 1H498516-1A NAETC-7816-1A <CDD1N>
(U11) Roulette motor PC board assy 1H498516-1B NAETC-7816-1B <CPA4P>
(U12) Loading motor PC board assy 1H498517-1A NAETC-7817-1A <CDD1N>
(U12) Loading motor PC board assy 1H498517-1B NAETC-7817-1B <CPA4P>
(U13) Disc sensor PC board assy 1H498518-1A NAETC-7818-1A <CDD1N>
(U13) Disc sensor PC board assy 1H498518-1B NAETC-7818-1B <CPA4P>
U30 Power supply unit ! 8910-0740-0 NGPS-0036-100-120V <CDD1N>
U30 Power supply unit ! 8910-0750-0
NGPS-0037-100-240V <CPA4P>
