Onkyo DV-CP702 Service Manual

PRINTED CIRCUIT BOARD PARTS LIST-2
U3 : Front disp. PC board assy NADIS-7808-1A <CDD1N>, NADIS-7808-1B <CPA4P>
U4 : Mecha. Control PC board assy NADG-7809-1A <CDD1N>, NADG-7809-1B <CPA4P
U5 : Video output terminal PC board as NAVD-7810-1A <CDD1N>, NAVD-7810-1B <CPA4P>
U6 : Audio output terminal PC board a
s
NAAF-7811-1A <CDD1N>, NAAF-7811-1B <CPA4P>
U7 : Disc select switch PC board assy NASW-7812-1A <CDD1N>, NASW-7812-1B <CPA4P>
U8 : Key operation PC board assy NASW-7813-1A <CDD1N>, NASW-7813-1B <CPA4P>
U9 : Standby switch PC board assy NASW-7814-1A <CDD1N>, NASW-7814-1B <CPA4P>
U10 : LED display PC board assy NADIS-7815-1A <CDD1N>, NADIS-7815-1B <CPA4P>
U11 : Roulette motor PC board assy NAETC-7816-1A <CDD1N>, NAETC-7816-1B <CPA4P>
U12 : Loadin
g
motor PC board ass
y
NAETC-7817-1A <CDD1N>, NAETC-7817-1B <CPA4P>
CIRCUIT NO. PART NAME PART NO. DESCRIPTION REMARK N
D101 C-DIODE 4840-1660-0 1SS355
D101 or C-DIODE 480S-3520-3 1SS352
D102 C-DIODE 4840-1660-0 1SS355
D102 or C-DIODE 480S-3520-3 1SS352
D103 C-DIODE 4840-1660-0 1SS355
D103 or C-DIODE 480S-3520-3 1SS352
D104 C-DIODE 4840-1660-0 1SS355
D104 or C-DIODE 480S-3520-3 1SS352
D401 C-DIODE 4840-1660-0 1SS355
D401 or C-DIODE 480S-3520-3 1SS352
D701 ZENER D 483H-2V71-3 UDZ2.7B
D702 ZENER D 483H-2V21-3 UDZ2.2B
D703 ZENER D 483H-4V31-3 UDZS4.3B
D731 C-DIODE 4840-1660-0 1SS355
D731 or C-DIODE 480S-3520-3 1SS352
D732 ZENER D 483H-5V11-3 UDZS5.1B
D733 C-DIODE 4840-1660-0 1SS355
D733 or C-DIODE 480S-3520-3 1SS352
D734 C-DIODE 4840-1660-0 1SS355
D734 or C-DIODE 480S-3520-3 1SS352
D801 LED 3700-2824-B SLR-343BBT-XG
D801 or LED 3700-2835-B SLR-343BBT-XH
D801A HOLDER 4171-0021-0 (LED)LA-5-6
D802 LED 3700-2824-B SLR-343BBT-XG
D802 or LED 3700-2835-B SLR-343BBT-XH
D802A HOLDER 4171-0021-0 (LED)LA-5-6
D803 LED 3700-2531-R SLR-342VR
Q109 TR 485A-1140-3 DTA114YKA
Q109 or TR 4852-4070-3 RN2407
Q109 or TR 4860-3440-3 KRA107S
Q110 TR 485C-1140-3 DTC114YKA
Q110 or TR 4851-4070-3 RN1407
Q110 or TR 4851-07S0-3 KRC107S
Q201 IC 3131-8760-0 LA73054
Q202 TR 485C-1140-3 DTC114YKA
Q202 or TR 4851-4070-3 RN1407
Q202 or TR 4851-07S0-3 KRC107S
Q203 TR 485A-1140-3 DTA114YKA
Q203 or TR 4852-4070-3 RN2407
Q203 or TR 4860-3440-3 KRA107S
Q401 IC 3132-0180-0 PCM1742KE
Q403 IC 3131-9970-0 NJM4580M-D
