STANDBY/ON button
This button is used to set the DV-CP702 to On or
Standby.
Don't turn on the power until you've completed, and
double checked all connections.
STANDBY indicator
This indicator lights up when the DV-CP702 is in
Standby mode.
Disc tray
The disc tray has six bays for loading up to six discs.
Disc tray light
This light illuminates the disc tray. It comes on when the
DV-CP702 is turned on, and is brighter while the disc
tray is open.
DISC SKIP button
This button is used to select the disc bays (i.e., rotate the
disc tray) when loading or removing discs, and to select
discs for playback.
DISC SELECT 1-6 buttons
These buttons are used to select discs. Playback starts
automatically when a disc is selected with these buttons.
Open/Close [ ] button
This button is used to open and close the disc tray.
LAST MEMORY button
This button is used with the Last Memory function.
DIMMER button
This button is used to adjust the display brightness.
DISPLAY button
This button is used to display information about the cur-
rent disc, title, chapter, or track, including the elapsed
time, remaining time, total time, and so on.
REPEAT button
This button is used with the Repeat function.
Display
Remote control sensor
This sensor receives control signals from the remote
controller.
Previous [ ] button
This button is used to select the previous chapter or
track. During playback it selects the beginning of the
current chapter or track.
Next [ ] button
This button is used to select the next chapter or track.
PAUSE [ ] button
This button is used to pause playback.
CHAIN MODE button
This button is used with the Chain mode function.
STOP [ ] button
This button is used to stop playback.
PLAY/ENTER [ ] button
This button is used to start playback and to cancel fast
forward and fast reverse. It's also used to start Chain
mode playback.
1
2 3 4
5
6
7
8 9 10
11 12 13 14 15 16
1
2
3
4
5
6
7
8
9
17 18 19
17
18
19
10
11
12
13
14
15
16
DV-CP702
PANEL VIEW-1
FRONT PANEL
